122-101 Mitutoyo Blade Micrometer 0-25mm

122-101 Mitutoyo Blade Micrometer 0-25mm

  • $ 294.50
  • Save $ 15.50


Mitutoyo Blade Micrometer

The anvil and the spindle have a blade for measuring the groove diameter of shafts, keyways, and other hard-to-reach portions.

Specifications include...

  • 0-25mm Measuring Range
  • 0.01mm Graduation
  • + 3um Accuracy

Features include...

  • Ratchet Stop for constant force
  • Supplied in fitted case

Blade Dimensions...

  • 0.030" Wide
  • 0.236" Tall
  • 0.256" Long
