122-104 Mitutoyo Blade Micrometer 75-100mm
Mitutoyo Blade Micrometer
The anvil and the spindle have a blade for measuring the groove diameter of shafts, keyways, and other hard-to-reach portions.
Specifications include...
- 75-100mm Measuring Range
- 0.01mm Graduation
- + 3um Accuracy
Features include...
- Ratchet Stop for constant force
- Supplied in fitted case
Blade Dimensions...
- 0.030" Wide
- 0.236" Tall
- 0.256" Long
