122-104 Mitutoyo Blade Micrometer 75-100mm

Mitutoyo

122-104 Mitutoyo Blade Micrometer 75-100mm

$ 335.35 $ 353.00


Mitutoyo Blade Micrometer

The anvil and the spindle have a blade for measuring the groove diameter of shafts, keyways, and other hard-to-reach portions.

Specifications include...

  • 75-100mm Measuring Range
  • 0.01mm Graduation
  • + 3um Accuracy

Features include...

  • Ratchet Stop for constant force
  • Supplied in fitted case

Blade Dimensions...

  • 0.030" Wide
  • 0.236" Tall
  • 0.256" Long
