573-282-20 Mitutoyo Snap Caliper

Mitutoyo

573-282-20 Mitutoyo Snap Caliper 6"

$ 466.45 $ 491.00


Mitutoyo 0-6" (0-150mm) Digimatic Snap Caliper with SPC output.

FEATURES:

  • The ABSOLUTE Digimatic snap caliper features a spring-loaded mechanism to allow quick and efficient GO/NO-GO inspection for mass production parts..
  • With SPC data output.
  • Supplied in fitted plastic case.
Technical Data
  • 0-6" / 150mm Measuring Range
  • Resolution: .0005" / 0.01mm
  • Repeatability: .0005” / 0.01mm
  • Display: LCD
  • Length standard: ABSOLUTE electrostatic capacitance type linear encoder
  • Measuring force: 7N to 14N (700gf to 1400gf)
  • Jaw retraction: 2mm
  • Max. response speed: Unlimited
  • Battery: SR44 (1 pc.), 938882 Battery life: Approx. 3.5 years under normal use
 Functions
Origin-set, Zero-setting, Power On/Off, Data output, inch/mm conversion (inch/mm models)
Alarm: Low voltage, Counting value composition error
